The Workgroup Server produces a metric called CONN_USED. This metric relates to the connection string used to connect to the manager when there are multiple connection strings provided. This could represent a host name, IP address, or virtual name depending on what is included in the connection string.

Based on the Manager technology, the strings returned will be as follows:

IBM MQ

When ConnectionName has only 1 entry, CONN_USED returns that entry, whether it is active or not.
When ConnectionName has multiple entries, and the second or third is active, CONN_USED returns the active entry.
When ConnectionName has multiple entries, and none are active, CONN_USED returns the last connected IP.

Examples

Only 1 entry, whether active or not:

ConnectionName=host1(1414)
CONN_USED=host1

Multiple entries and the 2nd is the active Queue Manager:

ConnectionName=host1(2015),host2(2015),host3(2015)
CONN_USED=host2

No active Queue Manager, but last connection was host1(1416):

ConnectionName=host1(1416),host2(1416)
CONN_USED=host1

For nsqcm (NV-632), the default behavior continues to use MQ native connection switching, which does not return the connection used. An additional option, -k, must be added to activate CM connection switching.

EMS

In EMS environments, when SrvUrl has only 1 entry, CONN_USED returns the domain of that entry (stripping out the scheme and port), whether it is active or not.
When SrvUrl has multiple entries, and the second or third is active, CONN_USED returns the domain of the active entry.
When SrvUrl has multiple entries, and there is no active EMS server, CONN_USED returns the last connected IP.

Examples

Only 1 entry, whether active or not:

SrvUrl=ssl://host1:55443
CONN_USED=host1

Example with the 2nd entry as the active EMS server:

SrvUrl=ssl://host1:8363,ssl://host2:8363
CONN_USED=host2

No active EMS server, but last connection was ssl://host1:8363:

SrvUrl=ssl://host1:8363,ssl://host2:8363
CONN_USED=host1

For nsqcmems (NV-634), the default behavior is to use CM connection switching and return connection string. To use EMS native connection switching, you must specify the following property, fault.tolerance.compat=true.

Solace

For nsqsolace (NV-635), CONN_USED returns the connected IP.

Example

Url=https://host1:443
CONN_USED=host1

Kafka

For nsqcmkafka (NV-636), CONN_USED returns the connected IP.

Example

Bootstrap=host1:9092,host2:9092,host3:9092
CONN_USED=host1

Typos and invalid entries will return what they can, based on the host parsing rules that have been applied.

RabbitMQ

For nsqcmrabbitmq (NV-637): the url that established the connection last is published.

When URL has only 1 entry, CONN_USED returns that entry, whether it is active or not.
When URL has multiple entries, CONN_USED returns the active entry.
When URL has multiple entries, and none are active, CONN_USED returns the last connected IP.

Examples

Only 1 entry, whether active or not:

URL= http://172.16.31.123:15276
CONN_USED= 172.16.31.123

Multiple entries and the 2nd is the active Queue Manager:

URL= http://172.16.31.123:15276,http://172.16.31.124:15276
CONN_USED= 172.16.31.124

No active Queue Manager, but last connection was http://172.16.31.123:15276:

URL= http://172.16.31.123:15276,http://172.16.31.124:15276
CONN_USED= 172.16.31.123

ACE/IIB

For nsqcmace (NV-646):

When URL has only 1 entry, CONN_USED returns that entry, whether it is active or not.
When URL has multiple entries, CONN_USED returns the active entry.
When URL has multiple entries, and none are active, CONN_USED returns the last connected IP.

Examples

Only 1 entry, whether active or not:

URL= http://172.16.31.123:4414
CONN_USED=172.16.31.123

Multiple entries and the 2nd is the active Queue Manager:

URL= http://172.16.31.123:4414,http://172.16.31.113:4416
CONN_USED= 172.16.31.113

No active Queue Manager, but last connection was http://172.16.31.123:4414:

URL= http://172.16.31.123:4414,http://172.16.31.113:4416
CONN_USED=172.16.31.123
